GRAIN DRYER TE

Tornum’s TE Batch Dryer is a versatile, cost-effective hot-air grain dryer designed for various needs. It features a self-discharging bottom section functioning as the drying zone, complete with drying laterals and an outlet shutter for efficient drying. All our grain dryers are constructed using hot-dip galvanized steel.

Product Description

Tornum’s TE Batch Dryer is an affordable, compact hot-air grain dryer that can be adapted to different needs. The grain dryer has a self-discharging bottom section. which is used as the drying zone, and is equipped with drying laterals and an outlet shutter, giving good drying economy. All our grain dryers are made from hot-dip galvanized steel.

INCLUDED
• Hot-air duct
• Buffer zone

OPTIONS
• Ladders and platforms
• Sight glass – simplifies inspection from the outside
• Increased buffer zone
• Control – time, weight or temperature
• Moist air duct
• Level Indicator
• Fire detection system

Model:	Volume (m³):	Height (mm):	Max gross power (kW):
TS2-04-1	8.3	4155	179
TS2-05-1	9.7	4690	179
TS2-06-1	11.1	5225	179
TS2-07-1	12.5	5760	245
TS2-07-2	14.5	6295	245
TS2-08-2	15.9	6830	343
TS2-09-2	17.3	7365	343
TS2-10-2	18.7	7900	343
TS2-10-3	20.7	8435	343
TS2-11-3	22.1	8970	343
TS2-12-3	23.5	9505	640

Model:	Volume (m³):	Total height (mm):	Max gross power (kW):
TS3-04-1	12.3	4730	245
TS3-05-1	24.4	5265	245
TS3-06-1	16.5	5800	245
TS3-07-1	18.6	6335	343
TS3-07-2	21.6	6870	343
TS3-08-2	23.7	7405	343
TS3-09-2	25.8	7940	640
TS3-10-2	27.9	8475	640
TS3-10-3	30.9	9010	640
TS3-11-3	33.0	9545	640
TS3-12-3	35.1	10080	640
