BATCH DRYER TS

Tornum’s Batch Dryer TS is customizable for various capacity needs and features adjustable shutters for drying smaller batches.

Product Description

Tornum’s Batch Dryer TS can be adapted to different capacity requirements and is equipped with adjustable shutters for drying smaller batches.

There is a discharge section between the dryer sections and the discharge hopper, which makes it possible to re-circulate the batch without having to empty the entire unit. This helps ensure even drying, a high quality end product and good heating economy.

All our grain dryers are made from hot-dip galvanized steel.

INCLUDED
• Level indicator
• Moist air duct
• Discharge section
• Buffer zone

OPTIONS
• Fire detection system
• Ladders and platforms
• Increase in buffer zone
• Control – moisture content or temperature
• Discharge – interval

Model: Volume (m³): Height (mm): Max gross power (kW):
TS2-04-1 8.3 4155 179
TS2-05-1 9.7 4690 179
TS2-06-1 11.1 5225 179
TS2-07-1 12.5 5760 245
TS2-07-2 14.5 6295 245
TS2-08-2 15.9 6830 343
TS2-09-2 17.3 7365 343
TS2-10-2 18.7 7900 343
TS2-10-3 20.7 8435 343
TS2-11-3 22.1 8970 343
TS2-12-3 23.5 9505 640

Model: Volume (m³): Height (mm): Max gross power (kW):
TS3-04-1 12.3 4730 245
TS3-05-1 24.4 5265 245
TS3-06-1 16.5 5800 245
TS3-07-1 18.6 6335 343
TS3-07-2 21.6 6870 343
TS3-08-2 23.7 7405 343
TS3-09-2 25.8 7940 640
TS3-10-2 27.9 8475 640
TS3-10-3 30.9 9010 640
TS3-11-3 33.0 9545 640
TS3-12-3 35.1 10080 640
